Product Description

< >

Overview

Product Attributes

Model No.: Voton

Supply Ability & Additional Informations

Transportation: Ocean

Port: Qingdao Port

Payment Type: L/C,T/T

Incoterm: FOB,CIF,EXW

Product Details

FDX700-1:2 technical parameters
Maximum power p	700kW
Input torque T	3000Nm
Single pump power p	330kW
Maximum torque of single pump T	1800Nm
Maximum input speed n	230orpm
Maximum output speed n	2700rpm
Shell material	cast iron

Slow down	0.673	0.740	0.813	0.891	0.977
Growth rate	1.486	1.351	1.230	1.122	1.024



Product Categories : Transfer Case Series

Company Overview

Jinan Voton Machinery Equipment Co., Ltd. mainly deals in the following products: 1. Hydraulic products: Eaton, Danfoss, Linde all series of hydraulic products. HydraForce threaded cartridge valve, Nimco multi-way valve in Sweden. Main business: hydraulic pumps, hydraulic motors 2. Transfer case products: According to market demand, we develop and produce "Wharton" brand transfer case by ourselves. The meticulous design, precise processing and fine assembly ensure the excellent quality of the transfer case and have been recognized by the user. Jinan Voton is willing to establish long-term cooperative relations with enterprises with strong strength, reasonable prices and excellent service. Product Application Field Ship-involving drop gear, warehouse cover, crane, hydraulic steering gear, valve remote control and other systems. Construction machinery-involving road rollers, pavers, milling machines, graders, road mixers, spreaders, skid steer loaders, busy at both ends, cranes, crawler cranes, aerial work vehicles, flatbed trucks, cement mixer trucks , Concrete pump trucks, bulldozers, railway locomotives, oilfield logging / cementing / workover / sand mixing equipment, airport vehicles, port equipment, coal mining machinery, trenchless drilling rigs, rotary drilling rigs, anchoring and prospecting machinery, forklifts, Hydraulic systems such as rice harvesters and large and medium horsepower tractors. Agricultural machinery-cotton picking machine, green storage machine, high ground clearance spraying machine, etc. Metallurgy, cement, thermal power, aviation and other industries are also developing in the market.
